Description
Powered by the MPERIA platform the VIAjet V-Series features Matthews™ DOD valve jet ink jet technology that marks on porous and non-porous substrates including metal, paper and pulp, wood, concrete, and plastic. The VIAjet V-Series is the ideal ink jet marking and coding solution for challenging industrial environments as well as packing applications. Matthews™ DOD print heads are the fastest in the industry, marking over 244 meters/min (800 fpm) with the longest life “ over 6 billion firings per head.
The V-Series features large character print, ranging from 3mm to 127 mm (1/8³ to 5³), and an ability to stack print heads for large logos and graphics. These features, combined with its durable design makes V-Series ideal to meeting the demands of extreme environments, such as OSB plants, paper mills and steel mills.
MPERIA , Matthews™ universal print platform operates the VIAjet V-Series and allows customers to control multiple production lines, integrate order processing, populate production data from order processing files and interface with new or existing databases- all from a single controller.
V-Link, an enclosed module featuring an internal power supply and print head driver board, enables communication between the DOD print head technology and the MPERIA controller through an Ethernet connection. Each V-Link can be stacked and networked through MPERIA , providing a flexible and scalable system for small or very large applications.
Features
Print Capabilities & Features:
- Logos
- Date and time clocks
- Sequential and batch counters
- True type fonts with density settings
- Bi-directional printing
- Barcodes and 2D code
- Longest life for DOD valve print heads, with over 6 billion activiations between rebuilds
- Extensive selection of fast dry and / or pigmented inks available
- 7″ – 12″ (177mm – 304mm) touchscreen controllers are available with various IP ratings and performance depending on your demand
- Remote connectivity (Virtual Network Computing)
- Effortless integration with ERP/MRP/WMS systems
MPERIA Controller:
- Controls multiple production lines
- Combination of multiple inkjet technologies
- Stack print heads for extra print height and resolution
- Touchscreen interface
- Built-in database
- IP20 / IP65 versions
- Network-ready
- Simple message creation & editing
- Password-protected user levels
- Troubleshooting / maintenance screens
- Virtually no storage limits for number of messages / logos, message length, types of barcodes and time codes, etc.
- Available in 7″;-15″
- On-board image editor
- Virtual simulator
- Intuitive program design
- Windows / Codesoft driver
- TrueType fonts, grayscale / color images
- Guided installation /
- Multilingual with full BIDI support
Matthews Marking VIAjet V-Series
Model
VIAjet V-Series
Description
Powered by the MPERIA platform the VIAjet V-Series features Matthews™ DOD valve jet ink jet technology that marks on porous and non-porous substrates including metal, paper and pulp, wood, concrete, and plastic. The VIAjet V-Series is the ideal ink jet marking and coding solution for challenging industrial environments as well as packing applications. Matthews™ DOD print heads are the fastest in the industry, marking over 244 meters/min (800 fpm) with the longest life “ over 6 billion firings per head.
The V-Series features large character print, ranging from 3mm to 127 mm (1/8³ to 5³), and an ability to stack print heads for large logos and graphics. These features, combined with its durable design makes V-Series ideal to meeting the demands of extreme environments, such as OSB plants, paper mills and steel mills.
MPERIA , Matthews™ universal print platform operates the VIAjet V-Series and allows customers to control multiple production lines, integrate order processing, populate production data from order processing files and interface with new or existing databases- all from a single controller.
V-Link, an enclosed module featuring an internal power supply and print head driver board, enables communication between the DOD print head technology and the MPERIA controller through an Ethernet connection. Each V-Link can be stacked and networked through MPERIA , providing a flexible and scalable system for small or very large applications.
